Network Switches

Connectivity and control over all your devices

Meraki Go Network Switches

Unify your WiFi-enabled and plugged in devices for business efficiency & simplicity

Remote access and control, all from the mobile app

Apply bulk settings to all ports to save time

Simply Connect Your Tech

With Meraki Go network switches, you can have port availability to securely connect the other technologies you rely on and as your business grows to include more technology, Meraki Go easily scales with your business.

Compare POE Network Switches

Find out which network switch is right for your business.
Choose between 8, 24 or 48-port switches.

Switching Capacity

20 Gbp/s

56 Gbp/s

104 Gbp/s

Interface

8 x RJ45; 2 x 1G SFP uplink

24 x RJ45; 2 x 1G SFP uplink; RJ45 Management port

48 x RJ45; 2 x 1G SFP uplink; RJ45 Management port

Power

input: 100 - 240 VAC, 47-63 Hz; consumption: 7-88W

input: 100 - 240 VAC, 47-63 Hz; consumption: 28-250W

input: 100 - 240 VAC, 47-63 Hz; consumption: 37-478W

Ethernet Switching Capabilities

802.1p QoS, 8 queues; 802.1Q VLAN & trunking up to 4,094 VLANs; 802.1w, 802.1D RSTP & STP; 802.1ab LLDP and CDP

802.1p QoS, 8 queues; 802.1Q VLAN & trunking up to 4,094 VLANs; 802.1w, 802.1D RSTP & STP; 802.1ab LLDP and CDP; MAC forwarding entries: 16K

802.1p QoS, 8 queues; 802.1Q VLAN & trunking up to 4,094 VLANs; 802.1w, 802.1D RSTP & STP; 802.1ab LLDP and CDP; MAC forwarding entries: 32K

Physical Dimensions

1.1 x 8.74 x 5.91” (2.8 x 22.2 x 15cm)

1.73 x 17.32 x 9.84” (4.40 x 44 x 25cm)

1.73” x 17.32” x 13.39” (4.40 x 44 x 34cm)

Mounting Options (Hardware Included)

Wall mountable or Desktop

1U Rack-mountable or Desktop

1U Rack-mountable or Desktop

Compare Network Switches

Find out which network switch is right for your business.
Choose between 8, 24 or 48-port switches.

Switching Capacity

20 Gbp/s

56 Gbp/s

104 Gbp/s

Interface

8 x RJ45; 2 x 1G SFP uplink

24 x RJ45; 2 x 1G SFP uplink; RJ45 Management port

48 x RJ45; 2 x 1G SFP uplink; RJ45 Management port

Power

input: 100 - 240 VAC, 47-63 Hz; consumption: 6-9W

input: 100 - 240 VAC, 47-63 Hz; consumption: 8-18W

input: 100 - 240 VAC, 47-63 Hz; consumption: 17-36W

Ethernet Switching Capabilities

802.1p QoS, 8 queues; 802.1Q VLAN & trunking up to 4,094 VLANs; 802.1w, 802.1D RSTP & STP; 802.1ab LLDP and CDP

802.1p QoS, 8 queues; 802.1Q VLAN & trunking up to 4,094 VLANs; 802.1w, 802.1D RSTP & STP; 802.1ab LLDP and CDP; MAC forwarding entries: 16K

802.1p QoS, 8 queues; 802.1Q VLAN & trunking up to 4,094 VLANs; 802.1w, 802.1D RSTP & STP; 802.1ab LLDP and CDP; MAC forwarding entries: 32K

Physical Dimensions

1.1 x 8.74 x 5.91” (2.8 x 22.2 x 15cm)

1.73 x 17.32 x 9.84” (4.40 x 44 x 25cm)

1.73 x 17.32 x 9.84” (4.40 x 44 x 25cm)

Mounting Options (Hardware Included)

Wall mountable or Desktop

1U Rack-mountable or Desktop

1U Rack-mountable or Desktop

How it works

Find out what devices you’ll need to set up your own Meraki Go network.

Security Gateway

The security gateway router plugs into your existing modem to access the internet service you already pay for.

Network Switch

The network switch connects to your gateway, giving you control over your bandwidth and ensures your critical devices have priority.

Access Points

Wifi access points allow all your digital devices to connect to the network. Add more access points to give you wider coverage.

Learn More
